Infineon FP35R12KT4-B15: High-Performance 35A 1200V IGBT Module for Industrial Drives and Power Conversion

The Infineon FP35R12KT4-B15 stands as a premier three-phase IGBT module engineered to meet the rigorous demands of modern industrial power electronics. Designed specifically for high-performance applications, this module integrates advanced IGBT4 technology to deliver superior efficiency, robustness, and thermal management in a compact package. With a rated current of 35A and a blocking voltage of 1200V, it is ideally suited for industrial motor drives, uninterruptible power supplies (UPS), solar inverters, and industrial welding systems where reliability and power density are critical.

A key strength of the FP35R12KT4-B15 lies in its low saturation voltage (Vce(sat)) and high switching speed, which collectively minimize conduction and switching losses. This results in higher system efficiency and reduced thermal stress, enabling cooler operation and extended lifespan of both the module and the entire application. The module incorporates a full-bridge configuration, featuring six IGBTs with corresponding anti-parallel diodes, providing a complete solution for three-phase inverter topologies.

Thermal performance is further enhanced through the use of AL2O3 ceramic substrates and low-inductance design, which improve heat dissipation and ensure stable operation under high load conditions. The module also offers high isolation voltage (≥2500 Vrms), meeting stringent safety standards for industrial equipment. Additionally, its solder-free press-fit pin technology simplifies assembly, reduces mounting time, and increases production reliability.

With its combination of high power density, efficiency, and durability, the Infineon FP35R12KT4-B15 empowers designers to build next-generation power conversion systems that demand compact size, high output, and dependable performance in challenging environments.

ICGOO

Infineon FP35R12KT4-B15: A high-efficiency, robust three-phase IGBT module optimized for industrial drives and power conversion, delivering superior thermal performance and reliability with advanced IGBT4 technology.
